K-Rain ProSeries 150 Valve

A solution for every situation, K-Rain® ProSeries 150 Valves offer the irrigation professional a wide array of features and benefits.

The 1″, 1-1/2″ and 2″ (2,5 cm, 3,8 and 5 cm) models have a removable metering pin and external bleed screw promoting easy maintenance and manual operation. The Jar-Top valve provides the professional contractor easy servicing access. The 1-1/2″ and 2″ (3,8 and 5 cm) models feature a removable inlet cap to easily modify configuration from globe to angle-style valve.  That’s right, flex for specs.

Features and Benefits

All Models

• Heavy Duty, Corrosion, and UV Resistant PVC Construction – Increases the life of the valve
• Manual External Bleed Screw – Provides for manual operation in system start up
• Manual Internal Bleed through Solenoid – Provides for manual operation without discharging water outside the valve
• Captured Plunger – Allows for the solenoid to be removed without losing the internal plunger
• Flow Control – Allows for precise flow adjustment
• External Bleed Screw with Removable Metering Pin – Allows for easy cleaning of the metering pin without disassembling the valve

1-1/2″ and 2″ Models

• Removable Inlet Cap – Allows for easy conversion from globe to angle-style valve
• Heavy Duty Santoprene® Diaphragm – Unique design improves durability of diaphragm

Jar-Top Medels

• Threaded Jar-Top – Allows for quick removal of the cap for easy servicing after installation
• Glass-Filled Nylon Screw Cap – Increased durability

Models

• 7101 1″ Female NPT Thread
• 7101-SL 1″ Female Slip
• 7101-BSP 1″ Female BSP Thread
• 7101-BSP-FC 1″ Female BSP Thread, with Flow Control
• 7101-FC 1″ Female NPT Thread, with Flow Control
• 7101-SL-FC 1″ Female Slip with Flow Control
• 7101-J 1″ Female NPT Thread Jar-Top
• 7101-J-SL 1″ Female Slip Jar-Top
• 7101-J-BSP 1″ Female BSP Thread Jar-Top
• 7101-J-MXB 1″ Male NPT Thread x 1″ Barb Jar-Top
• 7101-ANGLE 1″ Female NPT Thread
• 7101-ANGLE-FC 1″ Female NPT Thread, with Flow Control
• 7101-ANGLE-SL 1″ Female Slip
• 7101-ANGLE-SL-FC 1″ Female Slip with Flow Control
• 7101-ANGLE-BSP 1″ Female BSP Thread
• 7101-ANGLE-BSP-FC 1″ Female BSP Thread, with Flow Control
• 7115 1 1/2″ Female NPT Thread
• 7115-BSP 1 1/2″ Female BSP Thread
• 7102 2″ Female NPT Thread
• 7102-BSP 2″ Female BSP Thread

How to Specify 9 Volt solenoid

• 7101 -9VDC

Example: 7101-SL-9VDC
